SKF SY1.1/2FM 2 Bolt Pillow Block Bearing
£64.87
£54.06
In stock
SKU
SY1.1/2FM
Bore Size: 1.1/2" (38.1mm)
Housing Length: 6.89" (175mm)
Housing Width: 1.89" (48mm)
Bolt Hole Centres: 5.33" (135.5mm)
Housing Length: 6.89" (175mm)
Housing Width: 1.89" (48mm)
Bolt Hole Centres: 5.33" (135.5mm)
SY1.1/2FM 1.1/2inch Bore Y-bearing Plummer Block - Cast Housing & Eccentric Locking Collar
Bolt Hole Dia (N): 0.96inch (24.5mm)
Limiting Speed: 4800r/min
Bore Size (d): 1.1/2inch (38.1mm)
Bolt Hole Centres (J): 5.33inch (135.5mm)
Housing Length (L): 6.89inch (175mm)
Housing Width (A): 1.89inch (48mm)
Overall Height (H): 3.90inch (99mm)
Shaft Centre Height (H1): 1.94inch (49.2mm)
Bolt Hole Dia (N): 0.96inch (24.5mm)
Limiting Speed: 4800r/min
Bore Size (d): 1.1/2inch (38.1mm)
Bolt Hole Centres (J): 5.33inch (135.5mm)
Housing Length (L): 6.89inch (175mm)
Housing Width (A): 1.89inch (48mm)
Overall Height (H): 3.90inch (99mm)
Shaft Centre Height (H1): 1.94inch (49.2mm)
