PAG20S
£1,083.90
£903.25
In stock
SKU
FT-PAG20S
PRISMA PAG20 SA 180o ACTUATOR
PRISMA PAG20 SA 180o ACTUATOR
Features: 0-180ﾰ rotation angle to pilot 3 way ball valves. Double acting torques from 17 to 243.7 Nm at 6 bar. Single acting torques from 6.1 to 104 Nm end of spring. Rilsan and epoxy coated aluminium body. ATEX II 2G Ex h IIB T6 Gb / II 2D Ex h IIIC T80ﾰC Db certification. Conforms to ISO 5211, DIN 3337 and VDI/VDE 3845. NAMUR pneumatic connection for solenoid valve installation.
BearingShopUK holds a large stock of Process Valves and Instrumentation equipment, including the PAG20S Range of Pneumatic Actuator.
Please allow 3-4 days for delivery from our Fluid Power Branch.
Please view the below PDF for more information,
Features: 0-180ﾰ rotation angle to pilot 3 way ball valves. Double acting torques from 17 to 243.7 Nm at 6 bar. Single acting torques from 6.1 to 104 Nm end of spring. Rilsan and epoxy coated aluminium body. ATEX II 2G Ex h IIB T6 Gb / II 2D Ex h IIIC T80ﾰC Db certification. Conforms to ISO 5211, DIN 3337 and VDI/VDE 3845. NAMUR pneumatic connection for solenoid valve installation.
BearingShopUK holds a large stock of Process Valves and Instrumentation equipment, including the PAG20S Range of Pneumatic Actuator.
Please allow 3-4 days for delivery from our Fluid Power Branch.
Please view the below PDF for more information,
