L070 Jaw Coupling element "Spider
£3.24
£2.70
In stock
SKU
35570
Overall Diameter: 35 Assembled Length: 51 Hub Diameter: 35 Set Screw Size: M6
A jaw coupling is a type of motion control (servo) coupling designed to transmit torque by connecting two shafts while damping system vibrations, which protects other components from damage. Jaw couplings are composed of three parts including two metallic hubs and an elastomer insert called an element, but commonly referred to as a "spider".
seperatorTechnical Dimensions
| Nominal Torque (Nm) | 5.77 |
| Maximum Speed rev/min | 14000 |
| Pilot Bore (A) | 9 |
| Maximum Bore (A) | 19 |
| Overall Diameter (B) | 35 |
| Assembled Length(L) | 51 |
| Hub Width (C) | 19 |
| Hub Diameter (D) | 35 |
| Set Screw Position (F) | 9.5 |
| Set Screw Size | M6 |
