1021-0015

2 Bank 4 Way 3 Position Monoblock Valve P120
Description Manually or mechanically controlled hydraulic directional control valve. Designed for distribution and control of work flow between generator (pump) and executive mechanisms (cylinder, hydro-motor, etc.). manufactured with 1 to 7 plungers, with parallel or serial action, with common or individual back valve for each plunger, with or without safety valve., Construction Body is cast iron EN-GJL300. Plungers are made of carburised steel with hard chrome plating., Mounting The distributor is fixed with two bolts M8., Port Threads Sizes: P, T, N = 1/2" BSPP, A & B = 3/8" BSPP, Interchangeable With Walvoil SD5, All valves come standard with adjustable MRV (Main Relief Valve) set at 250 bar, adjustable from 20 to 250 bar., Includes standard lever
BearingShopUK holds a large stock of Hydraulic equipment, including the 1021-0015 Range of 2 Bank.

Please allow 3-4 days for delivery from our Fluid Power Branch.

Please view the below PDF for more information,
TS60381
